$65.86
$105.38
Description SECURITY Access Control Source/Destination IP Based Access Control Filtering • WEB Group Filtering§ • URL Filtering • Web Security§ ARP Inspection • Sending GARP Packets§ • ARP Scanning§ • IP-MAC Binding Attack Defense • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN HARDWARE FEATURES Standards and Protocols • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE 802.3x, IEEE 802.1q • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN Interface • 1 Gigabit WAN port • 2 Gigabit LAN/WAN ports • 2 Gigabit LAN ports • 1 USB2.0(supports USB LTE dongle‡) Network Media • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5e, 6 cable (Max 100 m) Fan Quantity Fanless Button Reset Button Power Supply External 12V/1A DC Adapter PoE Budget – Flash 128 MB NAND DRAM 256 MB DDR LED PWR, SYS, WAN (Link/Act), LAN (Link/Act), USB Dimensions ( W x D x H ) 6.2 × 4.0 × 1.0 in (158 × 101 × 25mm) Protection 4 kV surge protection Enclosure Steel Mounting Desktop/Wall-mount Max. Power Consumption 7.94 W PERFORMANCE DPI Throughput TCP: 905 Mbps; UDP: 788 Mbps WireGuard VPN Throughput • 123.4 Mbps Concurrent Session 150,000 New Sessions /Second 2,600 NAT (Static IP) • Upload: 945.77 Mbps • Download: 938.79 Mbps • Bi-Directional: 1808.29 Mbps NAT(DHCP) • Upload: 945.54 Mbps • Download: 945.66 Mbps • Bi-Directional: 1802.77 Mbps NAT(PPPoE) • Upload: 939.71Mbps • Download: 939.43 Mbps • Bi-Directional: 1788.54 Mbps NAT (L2TP) • Upload: 815.55 Mbps • Download: 835.59 Mbps • Bi-Directional: 903.13 Mbps NAT (PPTP) • Upload: 813.23 Mbps • Download: 850.91 Mbps • Bi-Directional: 894.41 Mbps IPsec VPN Throughput • ESP-SHA1-AES256: 259.78 Mbps • ESP-SHA256-AES256: 260.81 Mbps • ESP-SHA384-AES256: 37.65 Mbps • ESP-SHA512-AES256: 38.32 Mbps OpenVPN • 21.70 Mbps L2TP VPN Throughput • Unencrypted: 640.99 Mbps • Encrypted: 77.31 Mbps PPTP VPN Throughput • Unencrypted: 759.55 Mbps • Encrypted: 75.80 Mbps SSL VPN Throughput – 66 Byte Packet Forwarding Rate • Upload/Download: 954.50 Mbps • Bi-Directional: 1130.00 Mbps 1,518 Byte Packet forwarding rate • Upload/Download: 997.50 Mbps • Bi-Directional: 1965.00 Mbps BASIC FUNCTIONS WAN Connection Type • Static • Dynamic IP • PPPoE(supports MRU Configuration) • PPTP • L2TP MAC Clone Modify WAN/LAN MAC Address† DHCP • DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP IPv6 StaticIP/SLAAC/DHCPv6/PPPoE/6to4Tunnel/PassThrough/Non-Address mode VLAN 802.1Q VLAN IPTV IGMP v2/v3 Proxy, Custom Mode, Bridge Mode Advanced Features Advanced Routing • Static Routing • Policy Routing • RIP§ • OSPF§ Bandwidth Control IP-based Bandwidth Control Load Balance • Intelligent Load Balance • Application Optimized Routing • Link Backup (Timing, Failover) • Online Detection NAT • One-to-One NAT • Multi-Net NAT • Port Forwarding • Port Triggering§ • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP Session Limit IP-based Session Limit VPN IPsec VPN • 20 IPSec VPN Tunnels • LAN-to-LAN, Client-to-LAN • Main, Aggressive Negotiation Mode • DES, 3DES, AES128, AES192, AES256, SHA2-384 and SHA2-512 • Encryption Algorithm • IPsec Failover • IKE v1/v2 • MD5, SHA1 Authentication Algorithm, SHA2 Authentication Algorithm • NAT Traversal (NAT-T) • Dead Peer Detection (DPD) • Perfect Forward Secrecy (PFS) PPTP VPN • PPTP VPN Server • PPTP VPN Client (10) ** • 16 Tunnels • PPTP with MPPE Encryption L2TP VPN • L2TP VPN Server • L2TP VPN Client (10) ** • 16 Tunnels • L2TP over IPSec OpenVPN • OpenVPN Server • OpenVPN Client (10)§ • 16 OpenVPN Tunnels • “Certificate Account” Mode • Full Mode WireGuard VPN • 20 Tunnels AUTHENTICATION Web Authentication • No Authentication • Simple Password* • Hotspot（Local User / Voucher*/ SMS*/ Radius*） • External Radius Sever • External Portal Sever* • LDAP§ Management Features Omada App Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. Centralized Management • Omada Cloud-Based Controller • Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller Cloud Access Yes. Requiring the use of OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller. Service Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) Maintenance • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute)§ • NTP Synchronize§ • Port Mirroring • CLI (only in Standalone Mode) • Syslog Support Zero-Touch Provisioning Yes. Requiring the use of Omada Cloud-Based Controller. Management Features • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration OTHERS Certification CE, FCC, RoHS Package Content • ER605 • Power Adapter • RJ-45 Ethernet Cable • Quick Installation Guide System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10 MAC OS, NetWare, UNIX or Linux Environment • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 10% to 90% non-condensing • Storage Humidity: 5% to 90% non-condensing
Router
