Description Product specs EAN6422956013202 PNSIH12005L052ACCU0B PhaseSingle-Phase TopologyTransformerless Max Efficiency97,3% Battery Mode Efficiency94,0% Battery supported48V Lithium or Lead Acid Input PV Max Power9KW Input PV Max Voltage550V Input PV Rated Voltage360V Input Max Current30A (2x15A) Input Max Short Circuit Current40A (2x20A) Input PV Start Voltage90V MPPT Operating Voltage70V-520V No MPPTs2 Max No PV Strings2 (1/1) Battery Voltage Range40V-60V Battery Charge/Discharge Power5KW / 5KW Battery Charge/Discharge Current120A / 120A Output Rated Voltage220V / 230V, L N PE Output Rated Power5KW Output Max Apparent Power5.5KVA Output Max Current25A ProtectionsDC switch Anti-islanding AC overcurrent AC short circuit DC reverse connection Surge Arrester (AC & DC Type III) Insulation detection Leakage current Parallel ConnectionYes IP RatingIP65 CoolingNatural Noise level DisplayLED APP Integrated CommunicationBluetooth, RS485 (BMS / CT / Meter / DRM) External Communication ModulesWiFi Smart Meter (included) Optional: GPRS, 4G, LAN OthersEPS (Emergency Power Supply) circuit for Battery mode Battery Charging from PV Only or from PV Grid Self Adaptation to BMS Transfer Time from/to Battery 10ms (typical) / 20ms (max) Operating Temperature -25°C – 60°C Relative Humidity 0 – 100% Max Operating Altitude 4000m Remote configuration and upgrade Dimensions (W x H x D)515 x 485 x 175 mm Weight24.6 Kg
