> Transmission properties: Category 5e> Area of application: Up to 100 MHz, 10/100Base-T, 1GBase-T> Norms: ISO/IEC 11801 3rd Ed., EN 50173-1, EIA/TIA 568-C> General properties:> Suitable for 483 mm (19") cabinet mounting> RJ45 female, 8P8C> Cable installation via LSA strips, color coded according to EIA/TIA 568 A & B> Cable fixing with smart cable ties> Tool-free installation> Technical properties:> RJ45 female material: ABS UL 94V-0> RJ45 female contact: Tinned phosphor bronze, 0.5 μ gold-plated contact> LSA termination clamp: Krone LSA , UL 94V-2, zinc plated phosphor bronze> Conductor plate: FR4, UL 94V-0> Physical properties:> Insertion force: 30N max. (IEC 60603-7-5)> Retention strength: 7.7 kg between jack and plug> Operation temperature: -20° C to 70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA/EIA 568 C)> 750 acc. to ISO/IEC 11801, IEC 60603-7-5> 200 acc. to ISO/IEC 11801, IEC 60603-7-5> IDC wire size: 22 – 26 AWG solid and stranded conductor> Insulation resistance: > 500 MOhm</p><p><span>> </span>Contact resistance: < 20 MilliOhm 500 MOhm> Contact resistance: > Dielectric strength: 1000 VDC (Contact/Contact), 1500 VDC (Contact/Ground)
